Product specifications
Article codeATEX Code zone 1 & 2ATEX Code zone 22Air output max.Air pressure max. Air temperature max.Connection voltage Power ConsumptionRecommended fusePlug connectionSwitchable Noise level Dimensions L x W x HDiameterIP classMobilityATEX Code zone 1&2
DRFCEX Series DRFC100EX II 2G Ex eb IIC T4 Gb II 2D Ex TC IIIB T120 DC 3950 m³/h 2000 Pa -20°C to 40°C 400 V/50 Hz 2.2kW 16A 400V/ 16A – 5-polig - 85 dB(A) 1000 x 1150 x 930 mm 250 mm IP55 mobile/ movable
DRFC300EX DRFC300EX II 2 G Ex eb IIC T4 Gb II 2D Ex TC IIIB T120 DC 10800 m³/h 2050 Pa -20°C to 40°C 400 V/50 Hz 5.5kW 16A 400V/ 16A – 5-polig - 91 dB(A) 1350 x 1150 x 1150 mm 450 mm IP55 mobile/ movable
